Zigbee DALI Gateway
A Zigbee to DALI protocol gateway that integrates DALI lighting systems into a Zigbee-based smart automation ecosystem. Supports up to 64 DALI nodes with DT8 compatibility for tunable white and RGBW control.
Protocol: Zigbee 3.0 + DALI Bus · Type: Zigbee to DALI Protocol Gateway · SRP: ₹1,00,000
Works with: Amazon Alexa · Google Home · Siri / Apple HomeKit
Description
A Zigbee to DALI protocol gateway that integrates DALI lighting systems into a Zigbee-based smart automation ecosystem. Supports up to 64 DALI nodes with DT8 compatibility for tunable white and RGBW control.
Translates Zigbee commands into DALI control signals for switching, dimming, grouping, scene control, and tunable white/RGBW operation. DIN rail or panel-mounted installation.
Specifications
| Specification | Value |
|---|---|
| Channels | Up to 64 DALI nodes |
| Recommended Load | DALI DT8 drivers and fixtures |
| Installation | DIN rail or panel-mounted |
| Compatibility | Zigbee automation platforms |
| Input Voltage | 24V DC |
| DALI Channels | 1 |
| Built-in DALI PS Output Voltage | 12–22.5V DC |
| Built-in DALI PS Output Current | 250mA max |
| DALI Current Consumption (PS disabled) | Max. 2mA |
| Max DALI Devices | 64 |
| Supported Device Types | DT6, DT8 Tc, DT8 XY, DT8 RGBWAF |
| Connectivity | Ethernet (RJ45) |
| Control Modes | Broadcast, group, scene, timer & schedule |
| Built-in Battery & RTC | Yes |
| Dimensions (L × W × H) | 110 × 53 × 65 mm |
Setup
Wired Gateway
- Connect via Ethernet to your router or switch.
- Power via USB-C.
- Add the gateway in Home Assistant (Zigbee integration → EZSP or Zigbee2MQTT).
- Begin pairing Zigbee devices.
Matter Gateway (Convergia)
- Connect via Ethernet.
- Add to Apple Home, Google Home, or SmartThings using the Matter QR code on the device.
- All Zigbee child devices appear automatically in the Matter fabric.
VRV Gateway
Bridges Zigbee to VRV/VRF air conditioning systems (Daikin, Mitsubishi, etc.).
- Connect the RS-485 port to the VRV indoor unit or centralised controller.
- Configure address and baud rate per your VRV system documentation.
DALI Gateway
Bridges Zigbee to DALI-2 lighting systems.
- Connect DALI bus terminals to the DALI line.
- Each gateway supports up to 64 DALI addresses.
- Configure via Home Assistant DALI integration.
Ordering
| SRP (incl. GST) | ₹1,00,000 |
| GST Rate | 18% |
| HSN Code | 85371010 |
