TOQ 4T+2F+1S
A multi-function Zigbee wall panel combining 4 load control buttons, 2 dedicated fan channels, and an integrated 6A utility socket in a single glass panel.
Protocol: Zigbee 3.0 · Type: Zigbee Touch Control Panel with Fan and Socket · SRP: ₹20,135
Works with: Amazon Alexa · Google Home · Siri / Apple HomeKit
Description
A multi-function Zigbee wall panel combining 4 load control buttons, 2 dedicated fan channels, and an integrated 6A utility socket in a single glass panel.
Ideal for rooms requiring lighting, fan, and power access control from one location. Each button configurable independently. Available in white or black glass with silver, gold, or black bezel.
Specifications
| Specification | Value |
|---|---|
| Channels | 4 + 2 fan |
| Max Switching | 10A per button channel |
| Recommended Load | Up to 4A per button channel; fans up to 120W each |
| Installation | Wall-mounted |
| Compatibility | Zigbee automation platforms |
Installation
Requirements
- Standard flush box compatible with panel dimensions
- Live, Neutral, Load wires
- Zigbee coordinator within range
Switch off the circuit breaker.
Mount the backplate/box to the wall.
Connect wiring per the channel labels on the panel.
Snap or screw the panel into position.
Restore power and pair with your Zigbee coordinator.
Configure scenes and buttons in the Smartify or Home Assistant UI.
Notes
- Touch panels must be grounded to avoid false triggers.
- Ensure the panel is flush against the wall for reliable capacitive touch detection.
Ordering
| SRP (incl. GST) | ₹20,135 |
| GST Rate | 18% |
| HSN Code | 85369090 |
