TOQ 8T
An 8-button Zigbee capacitive touch panel for load switching, scene triggering, and dimming control across up to 8 independent channels.
Protocol: Zigbee 3.0 · Type: Zigbee Touch Control Panel · SRP: ₹13,805
Works with: Amazon Alexa · Google Home · Siri / Apple HomeKit
Description
An 8-button Zigbee capacitive touch panel for load switching, scene triggering, and dimming control across up to 8 independent channels.
Each button is individually configurable for toggle or momentary operation. Supports dimming via compatible retrofit dimmer modules. Available in white or black glass with silver, gold, or black bezel and configurable backlight colour.
Specifications
| Specification | Value |
|---|---|
| Channels | 8 |
| Max Switching | 10A per channel |
| Recommended Load | Up to 4A per channel |
| Installation | Wall-mounted |
| Compatibility | Zigbee automation platforms |
Installation
Requirements
- Standard flush box compatible with panel dimensions
- Live, Neutral, Load wires
- Zigbee coordinator within range
Switch off the circuit breaker.
Mount the backplate/box to the wall.
Connect wiring per the channel labels on the panel.
Snap or screw the panel into position.
Restore power and pair with your Zigbee coordinator.
Configure scenes and buttons in the Smartify or Home Assistant UI.
Notes
- Touch panels must be grounded to avoid false triggers.
- Ensure the panel is flush against the wall for reliable capacitive touch detection.
Ordering
| SRP (incl. GST) | ₹13,805 |
| GST Rate | 18% |
| HSN Code | 85369090 |
TOQ 4T+1S
A 4-button Zigbee capacitive touch panel with an integrated 6A power socket and USB-C/USB-A charging ports, combining smart load control with utility power access in a single wall panel.
TOQ 10T
A 10-button Zigbee capacitive touch panel for comprehensive load switching and scene control across up to 10 independent channels in residential and commercial installations.
