1 Channel Zigbee Retrofit Relay (40A)
A heavy-duty single-channel Zigbee relay rated for direct switching of high-current loads up to 40A. Designed for high-power appliances such as water heaters, pumps, HVAC loads, and industrial equipment.
.b8421ca0.png)
Protocol: Zigbee 3.0 · Type: Heavy-Duty Switching Relay · SRP: ₹5,000
Works with: Amazon Alexa · Google Home · Siri / Apple HomeKit
Description
A heavy-duty single-channel Zigbee relay rated for direct switching of high-current loads up to 40A. Designed for high-power appliances such as water heaters, pumps, HVAC loads, and industrial equipment.
Installs behind an existing wall switch in a flush box or on DIN rail. Proper cable sizing, circuit protection, and installation practices are mandatory for safe operation at rated current. Communicates natively over Zigbee 3.0 with Home Assistant, and integrates with Matter and Apple HomeKit via a compatible hub.
Specifications
| Specification | Value |
|---|---|
| Channels | 1 |
| Max Switching | 40A |
| Recommended Load | High-power appliances and heavy electrical loads |
| Installation | Flush box or DIN rail |
| Compatibility | Home Assistant (native), Matter & Apple HomeKit (via hub) |
Installation
Requirements
- Existing wall switch in a flush box (≥ 60mm depth recommended)
- Live, Neutral, and Load wires in the flush box
- Zigbee coordinator within range
Turn off the circuit breaker for the affected circuit.
Remove the existing switch plate. The retrofit module sits behind the existing switch — no visible hardware change.
Connect wiring:
- Live → L input
- Neutral → N input
- Load → load output(s)
Fit the module into the flush box. Use DIN rail adapters for panel board installation.
Replace the switch plate.
Restore power. The device will blink — ready to pair.
Pair with your Zigbee coordinator.
Load Limits
- Standard relay: up to 4A direct. For 4–10A, use an external relay/SSR/contactor.
- 40A relay: rated for direct high-current switching. Proper cable sizing and circuit protection mandatory.
- Dimmer modules: resistive and leading-edge dimmable loads only. Not suitable for ceiling fans.
Shutter Module
The shutter module controls motorised curtains, blinds, and shutters:
- M1, M2 → motor up/down terminals
- Configure travel time in your coordinator for accurate position reporting.
Ordering
| SRP (incl. GST) | ₹5,000 |
| GST Rate | 18% |
| HSN Code | 85365090 |
