TAC K
A Zigbee rotary smart dial for intuitive control of lighting brightness, colour temperature, and device groups. Supports up to 3 individual lights or 3 lighting groups via rotate and push interaction.
Protocol: Zigbee 3.0 · Type: Zigbee Rotary Control Dial · SRP: ₹34,000
Works with: Amazon Alexa · Google Home · Siri / Apple HomeKit
Description
A Zigbee rotary smart dial for intuitive control of lighting brightness, colour temperature, and device groups. Supports up to 3 individual lights or 3 lighting groups via rotate and push interaction.
Rotate to adjust brightness or colour temperature. Push to switch between groups or trigger actions. Designed for wall-mounted installation.
Specifications
| Specification | Value |
|---|---|
| Channels | Up to 3 lights or 3 lighting groups |
| Installation | Wall-mounted |
| Compatibility | Zigbee automation platforms |
| Input Voltage | 110–240V AC 50/60Hz |
| Communication Protocol | Zigbee |
| Product Size | 86 × 86 × 25.4 mm (knob: 16mm) |
| Bottom Shell Depth | 28mm |
| Working Temperature | -10°C to +60°C |
| Working Humidity | ≤95% RH (non-condensing) |
Installation
Requirements
- Standard 2-module or 4-module flush box
- Live, Neutral, and Load wires available at the switch location
- Zigbee coordinator (gateway) within range
Turn off the circuit breaker for the circuit you're working on.
Remove the existing switch plate and pull out the wires.
Connect Live (L) → L terminal, Neutral (N) → N terminal, Load → the load terminal(s).
Tuck the module into the flush box and fit the TAC switch plate.
Restore power. The LED indicator will blink — the device is ready to pair.
Open your Zigbee coordinator app (Home Assistant, SmartThings, etc.) and put it in pairing mode.
Press and hold the switch for 5 seconds until the LED blinks rapidly — pairing begins.
Wiring Notes
- Neutral wire is required for all TAC switches.
- Maximum load per channel: see product specifications.
- For ceiling fans, use the TAC F (fan speed controller variant).
Ordering
| SRP (incl. GST) | ₹34,000 |
| GST Rate | 18% |
| HSN Code | 85365090 |
